Name: factory 5 Ton Manual Chain block 6m 2 ton hand chain Hoist with hooks
Brand: JCYC
Price: 19.8 USD

Brand Name : JCYC

Model Number : HSZ

MOQ : 1

Price : $19.8-$259/PC

Payment Terms : T/T, L/C, Western Union

Supply Ability : 3000pcs/mouth

Delivery Time : 3-7workdays

Packaging Details : cartons with plywood

Product name : chain block

Capacity : 0.5-20ton

Control Method : manual control

Chain material : G80 chain

Limit Switch : Including

Lifting height : 3-18m

Keywords : hand chain hoist, manual block

OEM : accept

Contact Now

factory 5 Ton Manual Chain block 6m 2 ton hand chain Hoist with hooks

Capacity ton	Lifting height m	Running test load KN	Effort required to lift rated load N	Strands of load chain	Diameter of load chain mm	Net weight kg/3M
0.5t	3-18	7.5	221	1	6	9
1t	3-18	15	304	1	6	12
1.5t	3-18	22.5	343	1	8	19
2t	3-18	30	410	2	6	19
3t	3-18	45	343	2	8	27
5t	3-18	75	414	2	10	42
10t	3-18	150	414	4	10	83
20t	3-18	300	414×2	8	10	193

factory 5 Ton Manual Chain block 6m 2 ton hand chain Hoist with hooks
